Mass production of this simple yet effectively designed product will be relatively inexpensive and simple to accomplish using current production means and technology.

The “Sky Hooks” are brackets formed from a high density
polyethylene (HDPE) material, and in the design of a
curved L-bracket with projecting base plates.

The base plate portions of the brackets measure one inch
in length by three inches in width by one-eighth of one
inch in depth (1” x 3” x 1/8 ”).

Extending from these base plate portions at approximately
ninety-degree (90º) angles are L-brackets with rounded
corners. The vertical portion of this L rises two and one-
fourth inches in length, bearing the same three-inch width
as the base but with a reduced depth of one- sixteenth of
one inch (2 1/4 ” x 3” x 1/16”).

The horizontal portion of the L extends two inches in length from the vertical portion at a ninety-degree
(90º) angle in the opposite direction of the base. The horizontal portion has a depth of one-sixteenth of one
inch (1/16”) and ends in a rounded peak.

Two (2) apertures to accommodate insertion of mounting screws are featured in each of the base plate portions, and in a centered position with a two-inch (2”) gap between these apertures.

Screws for insertion into these apertures measure two and one-eighth inches (2 1/8 ”) in length. These
screws total four (4) in number for application of the two (2) “Sky Hooks.”

Features

  • Curved L-brackets with projecting base plates.
  • Made of HDPE.
  • Measuring 2 1/4 ” x 3” x 1/16” at vertical portion.
  • Measuring 2” x 3” x 1/16” at horizontal portion.
  • Measuring 1” x 3” x 1/8 ” at projecting base plate.
  • Two (2) apertures in centered position of base plate, with 2” distance between them.
  • Screws of 2 1/8 ” length for application into apertures.

Benefits

  • Easily attaches upon skateboards.
  • Provides contact points for the feet of skateboarders.
  • Raises the skateboard when user raises his/her feet.
  • Maintains user contact upon the skateboard.
  • Maintains position of skateboard when user performs maneuvers.
  • Ensures retention of skateboard when user performs maneuvers.
  • Ensures contact between user and skateboard.
  • Eliminates the need to grip board by hand.
  • Allows user to retain erect/semi-erect position throughout skateboard use.
  • Eliminates prominent factor of falls from skateboards.
  • Helps user maintain balance.
  • Allows user to perform skateboard maneuvers much easier.
  • Allows user to perform skateboard maneuvers much safer.
  • Expands the skills of skateboard users.
  • Easy to apply upon skateboards.
  • Can appeal to a very large and growing user market.
  • Meets the needs of the newest members of this user market.
  • Can join a very successful product market.
